多输入多输出雷达发射天线低旁瓣设计

马晓峰; 汤永浩; 盛卫星

多输入多输出雷达发射天线低旁瓣设计

南京理工大学电子工程与光电技术学院, 江苏南京 210094

详细信息

作者简介:
马晓峰(1981-),男,江苏人,南京理工大学电子工程与光电技术学院讲师,博士生,研究方向为阵列信号处理、软件无线电等;汤永浩(1988-),男,江苏人,南京理工大学电子工程与光电技术学院博士生,研究方向为MIMO雷达信号处理;盛卫星(1966-),男,江苏人,南京理工大学电子工程与光电技术学院教授,博士生导师,研究方向为阵列天线与阵列信号处理、雷达目标电磁散射特性建模及应用、微波成像等。

通信作者:
马晓峰 E-mail:maxiaofeng@njust.edu.cn

中图分类号: TN957.3
计量
- 文章访问数: 109
- HTML全文浏览量: 8
- PDF下载量: 13
出版历程
- 收稿日期: 2012-02-28
- 网络出版日期: 2020-12-30
- 发布日期: 2012-12-30

Low sidelobe transmit antenna design for MIMO radar

School of Electronic and Optical Engineering, Nanjing University of Science and Technology, Nanjing Jiangsu 210094, China

摘要

摘要: 多输入多输出(MIMO)雷达发射波形的多样性,为发射方向图设计提供了更多的自由度。针对阵元等功率条件下获得低旁瓣高增益发射波束的问题,提出了一种采用极小极大准则优化设计发射波形相关矩阵的方法,并将该约束优化问题转换为无约束优化问题,便于采用经典迭代法求解。仿真结果表明:采用极小极大准则设计的发射方向图旁瓣区域平坦,最高旁瓣电平接近理论最低值。最后采用循环(CA)算法,获得易于数字阵列系统实现的相位编码信号,使用该相位编码信号得到的实际发射方向图与理论结果匹配良好。
- 低旁瓣 /
- 多输入多输出雷达 /
- 极小极大准则 /
- 无约束优化 /
- 循环算法
Abstract: Waveform diversity of MIMO radar provides more degrees of freedom for transmit beam-pattern design.Firstly,a min-max criterion is proposed for optimizing the correlation matrix of the transmit waveforms to solve the problem of lowsidelobe and high-gain transmit beam-pattern design under the uniform elemental power constraint.The constrained optimization problem is then converted into an unconstrained optimization problem,which can be solved by classical iterative algorithm. Simulation results show that the min-max sidelobe optimization method can obtain a transmit beam-pattern with flat sidelobe region and lower sidelobe level. Finally,phase-coded signals are optimized using the cyclic algorithm.The beampattern of designed phase-coded signals matches well with the theoretical results.
- low-sidelobe /
- MIMO radar /
- min-max criterion /
- unconstrained optimization /
- cyclic algorithm

HTML全文

参考文献(16)

林志强,姚敏立,沈晓卫.基于遗传算法多子阵平板天线旁瓣电平优化[J].电波科学学报,2011,26(2):369-375. LIN Zhiqiang,YAO Minli,SHEN Xiaowei.Sidelobe reduction of the planar antenna with multiple subarrays based on genetic algorithm[J].Chinese Journal of Radio Science,2011,26(2):369-375.(in Chinese)

黄飞,盛卫星,马晓峰.随机错位子阵阵列天线及其优化设计[J].电波科学学报,2008,23(5):917-921. HUANG Fei,SHENG Weixing,MA Xiaofeng.Plane antenna arrays with randomly staggered subarrays and its optimal design[J].Chinese Journal of Radio Science, 2008,23(5):917-921.(in Chinese)

DEFORD J F,GANDHI O P.Phase-only synthesis of minimum peak sidelobe patterns for linear and planar arrays[J].IEEE Trans on Antennas and Propagation, 1988,36(2):191-201.

闫秋飞,范国平,徐朝阳.一维唯相位低副瓣技术研究[J].船舶电子对抗,2009,32(5):52-55. YAN Qiufei,FAN Guoping,XU Chaoyang.Study of low side lobe technique with phase-only on linear arrays[J].Shipboard Electronic Countermeasure,2009, 32(5):52-55.(in Chinese)

DAUM F,HUANG J.MIMO radar:snake oil or good idea?[J].IEEE Aerospace and Electronic Systems Magazine,2009,24(5):8-12.

LI J,STOICA P.MIMO radar with co-located antenna:review of some recent work[J].IEEE Signal Processing Magazine,2007,24(5):106-114.

AITTOMAKI T,KOIVUNEN V.Signal covariance matrix optimization for transmit beamforming in MIMO radars[C]//The Forty-First Asilomar Conference on Signals,Systems and Computers.Pacific Grove, November 4-7,2007:182-186.

FUHRMANN D R,ANTONIO G S.Transmit beamforming for MIMO radar systems using signal crosscorrelation[J].IEEE Trans on Aerosp Electron Syst, 2008,44(1):171-186.

AHMED S,THOMPSON J S,MULGREW B,et al. Unconstrained synthesis of covariance matrix for MIMO radar transmit beampattern[J].IEEE Trans on Signal Processing,2011,59(8):3837-3849.

胡亮兵,刘宏伟,刘保昌,等.MIMO雷达发射方向图匹配和波形优化方法[J].西安电子科技大学学报:自然科学版,2009,36(6):1021-1033. HU Liangbing,LIU Hongwei,LIU Baochang,et al. Transmit beampattern matching design and waveform optimization for MIMO radar[J].Journal of Xidian University:Science and Technology,2009,36(6):1021-1033.(in Chinese)

STOICA P,LI J,ZHU X.Waveform synthesis for diversity-based transmit beampattern design[J]. IEEE Trans on Signal Processing,2008,56(6):2593-2598.

STOICA P,LI J,XIE Y.On probing signal design for MIMO radar[J].IEEE Trans on Signal Processing, 2007,55(8):4151-4161..

GERSHMAN A B,SIDIROPOULOS N D,SHAHBAZPANAHI M B,et al.Convex optimization based beamforming[J].IEEE signal processing magazine, 2010,27(3):62-75.

刘韵佛,刘峥,谢荣.一种基于拟牛顿法的MIMO雷达发射方向图综合方法[J].电波科学学报, 2008,23(6):1188-1193. LIU Yunfo,LIU Zheng,XIE Rong.Transmit pattern synthesis algorithm for MIMO radar based on newton-like method[J].Chinese Journal of Radio Science, 2008,23(6):1188-1193.(in Chinese)

AHMED S,THOMPSON J S,MULGREW B,et al.Finite alphabet constant-envelope waveform design for MIMO radar[J].IEEE Trans on Signal Processing, 2011,59(11):5326-5337.

TROPP J A,DHILLON I S,HEATH R W,et al. Designing structured tight frames via an alternating projection method[J].IEEE Trans Inf Theory, 2005,51(1):188-209.
