微小间隙静电放电中两种放电模式的影响研究

阮方鸣; 董墨; 吴亮; 王义; 周峰; 石丹; 高攸纲

微小间隙静电放电中两种放电模式的影响研究

阮方鸣^1,,
董墨²,
吴亮¹,
王义¹,
周峰³,
石丹³,
高攸纲³

1.
贵州师范大学电子信息系, 贵州贵阳 550001
2. 中国电子科技集团第三十研究所, 四川成都 610041
3. 北京邮电大学电子工程学院, 北京 100876

详细信息

作者简介:
阮方鸣,(1958-),男,贵州人,工学博士,教授,硕士生导师,IEEE正式会员,中国电子学会高级会员,中国电子学会电磁兼容分会委员会委员。2004.9-2005.9年日本名古屋工业大学电磁兼容研究所访问研究员。独立或以第一作者发表论文50篇,主持和完成国家级省部级项目10项。主要研究兴趣:静电放电理论与测试、电磁生物效应、电磁兼容设计、绿能传感器与物联网;董墨,(1986-),男,山西人,工程师,桂林电子科技大学毕业。现在电子科技集团第三十研究所工作,主要研究方向为设计与产品结构、工艺造型研究;吴亮,男,工学博士,贵州师范大学副教授。研究方向为物联网技术与网络客户行为研究、嵌入式系统应用。

通信作者:
阮方鸣 E-mail:ruan.fm9@gmail.com

中图分类号: O441.4
计量
- 文章访问数: 161
- HTML全文浏览量: 44
- PDF下载量: 14
出版历程
- 收稿日期: 2011-11-21
- 网络出版日期: 2020-12-30
- 发布日期: 2012-10-30

Effect analysis of two discharge modes on parameters in micro-gap electrostatic discharge

1.
Department of Electronic&Information Engineering, Guizhou Normal University, Guiyang Guizhou 550001, China
2. The 30 th Research Institute of China Electronic Science and Technology Group, Chengdu Sichuan 610041, China
3. School of Electronic Engineering, Beijing University of Post and Telecommunication, Beijing 100876, China

摘要

摘要: 设计实验讨论了被普遍认为是空气放电的带电体与受电体有相对运动速度的静电放电的参数变化性质。由于电极最终要碰触到放电靶上,所以,同时考虑接触放电模式的影响。在不同放电间隙情况下用静电放电发生器进行了实验,证实真实静电放电过程中存在两种放电模式。实验测量了在不同放电间隙状态下用静电放电发生器向靶运动放电的参数,分析了空气放电和接触放电对整个放电过程的作用影响。结果表明:有电极移动速度的静电放电应认为是接触放电与空气放电共同作用的综合放电过程。
- 模式 /
- 静电放电 /
- 移动速度
Abstract: There exist two discharge modes in real electrostatic discharge(ESD) events and in experiment with ESD generator. ESD with electrode moving velocity were regarded as air discharge in many previous literatures. Contact mode electrostatic discharge is an important factor in ESD events with electrode moving to the target and need to be considered because electrode finally collides with the target. Discharge results were measured in ESD experiment with ESD generator, and analysis is given for impact of two modes of air discharge and contact discharge on the whole ESD process. Mutual action of two modes of air discharge and contact discharge result in consequences of ESD with electrode moving to the target.
- mode /
- electrostatic discharge /
- moving velocity

HTML全文

参考文献(23)

POMMERENKE D. ESD:transient fields, arc simulation and rise time limit[J]. Journal of Electrostatics, 1995, 36(1):31-54.

POMMERENKE D.On influence of speed of approach, humidity and arc length on ESD breakdown[C]//Proc The 3rd ESD Forum. Grainau,1993:103-111.

SUMIDA A, YOSHIDA T, MASUI N. Effects of the relative humidity on ESD from the charged metal[J]. Seidenki Gakkai Koen Ronbunshu, 2006:43-44. (in Japanese)

BONISH S, POMMERENKE D, KALKNER W. Broadband measurement of ESD:risetimes to distinguish between different discharge mechanisms[J]. Electrostatics, 2002, 56(3):363-383,.

RUAN F M, GAO Y G, SHI D. Analysis on electrode speed correlation of discharge parameters applying short-gap electrostatic discharge model[C]//Proc IEEE International Conference on EMC. Detroit, August19-23, 2008:1-4.

阮方鸣, 高攸纲, 石丹, 等. 静电放电参数对电极速度的相关性及其机理分析[J]. 电波科学学报, 23(5):977-981. RUAN Fangming, GAO Yougang, SHI Dan. et al. Mechanism analysis of correlation between electrode moving speed and discharge parameters[J]. Chinese Journal of Radio Science, 2008, 23(5):977-981.(in Chinese)

阮方鸣, 石丹, 沈远茂, 等. 人体静电放电参数对带电电压的依赖关系研究[J]. 电波科学学报, 2009, 24(3):551-555. RUAN Fangming, SHI Dan, SHEN Yuanmao, et al. Analysis with Bernoulli theorem on speed moving effect of electrode in short-gap ESD[J]. Chinese Journal of Radio Science, 2009, 24(3):551-555. (in Chinese)

阮方鸣, 石丹, 杨乘, 等. 用Bernoulli方程分析小间隙放电中的电极速度效应[J]. 电波科学学报, 2009,24(5):979-982. RUAN Fangming, SHI Dan, YANG Cheng, et al. Investigation of discharge parameters relying on charge voltage in human-metal ESD event[J]. Chinese Journal of Radio Science, 2009, 24(5):979-982. (in Chinese)

BRAGISKI S I. Theory of the development of a spark discharge[J]. Sov Phys, 1958, JETP(7):1068-1074.

O'ROURKE R C. Investigation of the resistive phase in high power gas switching[R]. Lawrence Livemore Laboratories, University of California, 1977.

HYATT H M. The resistive phase of an air discharge and the formation of fast rise time ESD pulse[C]//Proc EOS/ESD Symp. Dallas,September 16-18,1992.

MEEK J M, CRAGGS J D. Electrical Breakdown of Gases[M]. New York:Wiley, 1978.

RENNINGER R G. Mechanisms of charged-device electrostatic discharge[C]//Proc. EOS/ESD Symp, 1991:127-143.

MESYATS. Physics of Pulse Breakdown in Gases[M]. Moscow:Nauka Publishers, 1991. (in Russian)

LIND L, WELSHER T L. From lightning to charged-device model electrostatic discharges[C]//Proc EOS/ESD Symp, 1992:67-75.

MARTIN J C. Multichannel gaps[M]. Aldermaston:Atomic Weapons Res Establishment, 1970.

RISTIC V M, DUBOIS G R. Time dependent spark-gap resistance in short duration arcs with semimetallic cathodes[J]. IEEE Trans Plasma Sci, 1978, 6(4):124-131.

TAKA Y, FUJIWARA O. Verification of spark-resistance formulae for micro-gap ESD. IEICE Transactions on Communication, E93-B(7):1801-1806.

MORI I, TAKA Y, FUJIWARA O. Current calculation model for contact discharge of charged human body[R]//IEICE Technical Report Electromagnetic Compatibility, 2004, 104(499):35-40.(in Japanese)

MORI I, TAKA Y, FUJIWARA O. Evaluation of breakdown voltage with discharge current in human-metal contact discharge[R]//IEICE Technical Report Electromagnetic compatibility, 2006, 106(433):59-63.(in Japanese)

MORI I, FUJIWARA O. Characteristics measurement of discharge current in air model discharge with ESD gun[J]. IEEJ Transactions on Electronics, Information and Systems,2005,125(12):1798-1804. (in Japanese)

BARAN J, SROKA J. Distortion of ESD generator pulse due to limited bandwidth of verification path[J]. Trans IEEE EMC, 2010, 52(4):797-803.

TAKA Y, ADACHI T, FUJIWARA O, et al. Reconstruction of discharge currents injected on calibration target from electrostatic discharge generator[C]//Proc 18th Int Symp Electromagn. Compat. Zurich, Switzerland, 2007:349-352.
