艇载共形稀疏阵列天线雷达成像研究

滕秀敏; 李道京

艇载共形稀疏阵列天线雷达成像研究

滕秀敏^1,2,,
李道京¹

1.
中国科学院电子学研究所微波成像技术重点实验室, 北京 100190
2. 中国科学院研究生院, 北京 100190

详细信息

作者简介:
滕秀敏,(1987-),女,吉林人,中国科学院电子学研究所硕博连读研究生,主要从事基于稀疏阵列天线的雷达成像技术方面的研究工作;李道京,(1964-),男,陕西人,研究员,博士生导师,主要从事雷达系统和雷达信号处理等方面的研究工作。

通信作者:
滕秀敏 E-mail:xmteng@163.com

中图分类号: TN957
计量
- 文章访问数: 98
- HTML全文浏览量: 28
- PDF下载量: 11
出版历程
- 收稿日期: 2011-11-14
- 网络出版日期: 2020-12-30
- 发布日期: 2012-08-30

Airship conformal sparse array radar imaging

TENG Xiumin^1,2,,
LI Daojing¹

1.
Science and Technology on Microwave Imaging Laboratory, Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China
2. Graduate University of Chinese Academy of Sciences, Beijing 100190, China

摘要

摘要: 基于平流层飞艇平台,研究了共形稀疏阵列天线雷达对静止目标成像及对运动目标探测的问题。针对三叶玫瑰线艇身模型,提出了共形稀疏阵列天线的布阵方式。雷达采用实孔径方式成像,各子阵同时发射多脉冲频分正交信号。利用各子阵多发多收的回波信号,采用后向投影(BP)算法完成各子带信号对静止目标的成像处理,再将子带信号成像结果相参累加以提高静止目标成像的距离向分辨率;将各子阵一发多收的多脉冲回波信号变换到距离-多普勒域,完成静止杂波抑制,对各子带信号采用压缩感知(CS)的方法在二维空间实现对运动目标图像的重建,再将子带信号重建结果非相参累加以提高运动目标探测的信噪比。仿真实验验证了本文方法的有效性。
- 稀疏阵列 /
- 雷达成像 /
- 共形天线 /
- 压缩感知(CS) /
- 运动目标探测
Abstract: Based on the stratospheric airship platform,the problems about stationary targets imaging and moving targets detection using conformal sparse array are investigated.A distribution scheme of the conformal sparse array is proposed for the airship with the trilobal roseline profile model.The real aperture imaging method is adopted by the radar.All the subarrays transmit multiple-pulse orthogonal frequency division signals simultaneously.The echo signals of multiple-input and multiple-output are used to achieve stationary targets imaging by the back projection(BP)algorithm for each sub band signal respectively.Then all these results are coherently accumulated to improve the range resolution.The multiple-pulse signals of single-input and multiple-output are transformed into the range-Doppler domain to achieve clutter suppression.The compressed sensing(CS)method is used to reconstruct the moving targets image in two-dimension for each sub band signal respectively.Similarly, all these results are incoherently accumulated to improve the SNR of moving targets detection.Simulation results demonstrate the validity of the method proposed in this article.
- sparse array /
- radar imaging /
- conformal antenna /
- compressed sensing(CS) /
- moving target detection

HTML全文

参考文献(15)

LI Daojing,HOU Yingni,HONG Wen.The sparse array aperture synthesis with space constraint[C]//8th European Conference on Synthetic Aperture Radar(EUSAR 2010).Germany,2010:950-953.

侯颖妮, 李道京, 尹建凤,等.基于稀疏综合孔径天线的艇载成像雷达研究[J].电子学报, 2008, 36(12):2377-2382.HOU Yingni,LI Daojing,YIN Jianfeng,et al.Airship imaging radar based on aperture synthesis of thinned array[J].Acta Electronica Sinica,2008,36(12):2377-2382.(in Chinese)

HOU Yingni, LI Daojing,HONG Wen.Airship radar imaging for stationary and moving targets based on thinned array and code division signal[C]//2nd Asia-Pacific Conference on Synthetic Aperture Radar(APSAR 2009).China, 2009:622-625.

夏中贤.平流层飞艇总体性能与技术研究[D].江苏南京:南京航空航天大学, 2006.XIA Zhongxian.Research on performance and technology of stratospheric airship[D]. Nanjing:Nanjing University of Aeronautics and Astronautics,2006.(in Chinese)

欧阳骏, 杨峰, 聂在平,等.基于遗传算法的载体上共形天线阵列优化[J].电波科学学报,2008,23(2):356-359.OUYANG Jun,YANG Feng,NIE Zaiping,et al.Optimizing design of conformal antennas array on platform with GA method[J].Chinese Journal of Radio Science,2008,23(2):356-359.(in Chinese)

张玉洁, 龚书喜, 王文涛,等.基于改进遗传算法的非规则共形阵的研究[J].电波科学学报, 2010, 25(4):689-695.ZHANG Yujie,GONG Shuxi,WANG Wentao,et al.Research on irregular conformal array using improved genetic algorithm[J].Chinese Journal of Radio Science, 2010, 25(4):689-695.(in Chinese)

SOUMEKH M.Synthetic aperture radar signal processing with MATLAB algorithms[M].New York:Wiley-Interscience,1999.

DONOHO D.Compressed sensing[J].IEEE Transactions on Information Theory,2006,52(4):1289-1306.

TELLO M,LÓPEZ-DEKKER P,MALLORQUÍ J J.A novel strategy for radar imaging based on compressive sensing[J].IEEE Transactions on Geoscience and Remote Sensing,2010,48(12):4285-4295.

侯颖妮, 李道京, 洪文,等.稀疏阵列微波暗室成像实验[J].电子与信息学报, 2010, 32(9):2258-2262. HOU Yingni,LI Daojing,HONG Wen,et al.Thinned array imaging experimental study in anechoic chamber[J].Journal of Electronics & Information Technology,2010, 32(9):2258-2262.(in Chinese)

黄琼, 屈乐乐, 吴秉横,等.压缩感知在超宽带雷达成像中的应用[J].电波科学学报,2010,25(1):77-82+202. HUANG Qiong,QU Lele,WU Bingheng,et al.Compressive sensing for ultra-wideband radar imaging[J].Chinese Journal of Radio Science,2010,25(1):77-82+202.(in Chinese)

侯颖妮.基于稀疏阵列天线的雷达成像技术研究[D].北京:中国科学院电子学研究所,2010. HOU Yingni.Study of radar imaging technology based on sparse array antenna[D].Beijing:Institute of Electronics,Chinese Academy of Sciences,2010.(in Chinese)

LORD R T,INGGS M R.High resolution SAR processing using stepped-frequencies[C]//1997 IEEE International Geoscience and Remote Sensing Symposium(IGARSS 1997). Singapore,1997:490-492.

HAN Bing,DING Chibiao,LIANG Xingdong,et al.A new method for stepped-frequency SAR imaging[C]//6th European Conference on Synthetic Aperture Radar(EUSAR 2006).Germany,2006.

TROPP J A, GILBERT A C. Signal recovery from random measurements via orthogonal matching pursuit[J].IEEE Transactions on Information Theory,2007,53(12):4655-4666.
