用于空间功率合成的线阵馈电焦散抛物曲面天线

谢泽明; 王立新; 阮水生

用于空间功率合成的线阵馈电焦散抛物曲面天线

华南理工大学电子与信息学院, 广东广州 510640

详细信息

作者简介:
谢泽明(1963-),男,广东人,华南理工大学电子与信息学院副教授,博士,硕士生导师,目前主要研究领域包括移动通信天线、无线射频识别技术(RFID)、射频与微波器件设计与仿真和空间功率合成技术等;王立新(1986-),男,广东人,华南理工大学电子与信息学院研究生。主要研究方向为阵馈反射面空间功率合成天线技术;阮水生(1986-),男,广东人,华南理工大学电子与信息学院研究生。主要研究方向为天线理论与技术。

通信作者:
谢泽明 E-mail:eezmxie@scut.edu.cn

中图分类号: TN820.1
计量
- 文章访问数: 95
- HTML全文浏览量: 26
- PDF下载量: 9
出版历程
- 收稿日期: 2011-05-26
- 网络出版日期: 2020-12-30
- 发布日期: 2012-04-29

Linear array feed caustic parabolic curved antenna for spatial power combinating

School of Electronic and Information Engineering, South China University of Technology, Guangzhou Guangdong 510640, China

摘要

摘要: 提出了一种用于空间功率合成的焦散抛物曲面天线,该反射面天线是由xoz平面的一条抛物线沿着yoz平面上的另一条抛物线正交扫描所形成的,天线用8单元E面喇叭线阵进行偏馈。研究了天线的反射面结构参数对天线性能的影响以及横向偏焦电扫描特性,给出了不同辐射方向下阵列的相位配置公式。仿真和实验结果表明:提出的方案可以在给定方向合成高增益波束,与同样线阵馈电的抛物柱面天线相比,H面3dB波束宽度从8.2°下降到了5°,天线增益提高了2.2dB.
- 空间功率合成 /
- 抛物曲面天线 /
- 波束扫描 /
- 阵馈反射面天线
Abstract: A caustic parabolic curved antenna for spatial power combination is proposed in this paper.The reflector antenna is formed by aparabola in the xoz plane orthogonal scanning along the other parabola in the yoz plane.And antenna is offset fed with a line array of 8 E-plane sector horns.Both the impact of antenna structural parameters to the antenna performance and the electric scanning properties of the transversal displacement from focus are studied.A formula is given to configure the phases of the array for a given beam deflection angle.Simulation and experiment show that the designed antenna can combine a high gain beam at a given direction.Compared with the parabolic cylindrical antenna with the same aperture, the H-plane 3dB beam width decreases from 6.9°to 5°, and the antenna gain increases by 2.2dB.
- spatial power combination /
- parabolic curved antenna /
- beam scanning /
- array feed reflector antenna

HTML全文

参考文献(10)

章宇兵, 张浩, 廖桂生.任意分散布阵短波通信干扰机空间功率合成技术[J].西安电子科技大学学报, 2006, 33(01):150-155. ZHANG Yubing, ZHANG Hao, LIAO Guisheng.A technology of spatial power-combination for the random decentralized jammer array[J].Journal of Xidian University, 2006, 33(01):150-155. (in Chinese)

DELISIO M P, YORK R A.Quasi-optical and spatial power combining[J].IEEE Transactions, 2002, 50(3):929-936.

郭晨, 张安学, 吴辉, 等.高功率超宽带双馈源抛物面天线设计与仿真[J].电波科学学报, 2008, 23(4):658-661. GUO Chen, ZHANG Anxue, WU Hui, et al.Design and simulation of a wide-beam high-power paraboloidal antenna with dual-source[J].Chinese Journal of Radio Science, 2008, 23(4):658-661. (in Chinese)

RAHMAT-SAMII Y, DUAN D W, GIRI D V, et al. Canonical examples of reflector antennas for high-power microwave applications[J].IEEE Transactions, 1992, 34(3):197-205.

钟哲夫.阵列馈源偏置抛物面天线合成高功率微波的研究[J].强激光与粒子束, 2003, 15(5):467-470. ZHONG Zhefu.Generating high-power microwave with array feed offset paraboloid antenna[J].High Power Laser & Particle Beams, 2003, 15(5):467-470. (in Chinese)

张亦希, 张恒伟.卫星阵馈反射面赋形波束天线窗口效应的研究[J].电波科学学报, 2010, 25(6):1046-1051. ZHANG Yixi, ZHANG Hengwei.Window effects of array-fed reflector satellite shaped-beam antennas[J]. Chinese Journal of Radio Science, 2010, 25(6):1046-1051. (in Chinese)

张荣幸, 谢泽明, 褚庆昕.偏馈抛物柱面型空间功率合成天线研究[J].微波学报, 2008, 24(4):10-14. ZHANG Rongxing, XIE Zeming, CHU Qingxi.Study of offset parabolic cylindrical reflector antenna for spatial power combining[J].Journal of Microwaves, 2008, 24(4):10-14. (in Chinese)

谢泽明, 张荣幸, 熊尚书.用于空间功率合成天线的功分喇叭阵列[J].强激光与粒子束, 2011, 23(2):463-466. XIE Zeming, ZHANG Rongxing, XIONG Shangshu. Power dividing horn array for parabolic cylindrical spatial power combining antenna[J].High Power Laser &Particle Beams, 2011, 23(2):463-466. (in Chinese)

刘少东, 焦永昌, 张福顺.宽角扫描赋形对称单反射面天线的优化设计[J].电波科学学报, 2005, 20(5):627-631. LIU Shaodong, JIAO Yongchang, ZHANG Fushun. Optimal design of shaped symmetric single reflector antenna for wide-angle scanning[J].Chinese Journal of Radio Science, 2005, 20(5):627-631. (in Chinese)

李高升, 刘继斌, 何建国.抛物面天线馈源偏焦的理论及应用研究[J].雷达与对抗, 2004, 24(3):38-41. LI Gaosheng, LIU Jibin, HE Jianguo.Study on theory and application of focus excursion of paraboloid feed source[J].Radar &Ecm, 2004, 24(3):38-41. (in Chinese)
