极区电离层加热能量吸收率的非相干散射测量

徐彬; 王占阁; 程木松; 许正文; 吴健; 吴军; 薛昆

极区电离层加热能量吸收率的非相干散射测量

徐彬^1,2,,
王占阁¹,
程木松³,
许正文¹,
吴健¹,
吴军¹,
薛昆¹

1.
中国电波传播研究所, 电波环境特性及模化技术重点实验室, 山东青岛 266107
2. 中国科学院空间天气学国家重点实验室, 北京 100190
3. 西安电子科技大学理学院, 陕西西安 710071

详细信息

作者简介:
徐彬(1982-),男,辽宁人,博士,主要研究方向为非相干散射雷达和电离层加热;王占阁(1984-),女,河南人,现为中国电波传播研究所硕士研究生,主要研究方向为电离层加热数值仿真;程木松(1986-),男,黑龙江人,现为西安电子科技大学无线电物理专业硕士研究生,主要研究方向为非平衡态非相干散射理论。

通信作者:
徐彬 E-mail:jasur1982@sina.com

中图分类号: TN95
计量
- 文章访问数: 100
- HTML全文浏览量: 21
- PDF下载量: 16
出版历程
- 收稿日期: 2011-05-25
- 网络出版日期: 2020-12-30
- 发布日期: 2012-04-29

Measurement of energy absorption rate by incoherent scatter radar in polar ionospheric heating experiment

1.
Science and Technology on National Key Laboratory of Electromagnetic Environment Laboratory, China Research Institute of Radiowave Propagation, Qingdao Shandong 266107, China
2. State Key Laboratary of Space Weather, Chinese Academy of Science, Beijing 100190, China
3. School of Science, Xidian University, Xi'an Shaanxi 710071, China

摘要

摘要: 基于稳态电子能量和动量方程,结合2009年8月电离层加热实验中非相干散射雷达实测的电子密度、电子温度和离子温度对反射高度附近的电波能量吸收率进行了估算。根据计算结果,可得到显著的电波能量吸收率的空间分布结构,能量吸收基本呈近高斯分布,但结构在横向和纵向上并不沿能量吸收中心对称。0.6MHz附近,电波能量吸收率随频差变化的曲线存在锐边界,临界状态下时(两组加热机制的交界)才会取得最佳的加热效果,这对电波能量吸收率经验和半经验模型的建立有重要意义。
- 电波能量吸收率 /
- 电离层加热 /
- 非相干散射雷达 /
- 电子温度与密度
Abstract: Based on energy and momentum equations, the energy absorption flux near the reflection height is calculated by using the electron density, electron temperature and ion temperature measured in the heating campaign on August 16-19 2009.It is shown that the energy absorption flux is close to Gauss distribution, but the structure is not symmetric along beam absorption centre.The curve of absorption maximum with frequency difference exists break point near 0.6MHz, and we can carry out an optimization heating in a critical state, which is important for building the experiential and semi-experiential model of energy absorption flux.
- energy absorption flux /
- ionospheric heating /
- incoherent scatter radar /
- electron temperature and density

HTML全文

参考文献(19)

GUREVICH A V.Nonlinear Phenomena in the Ionosphere[M].Berlin:Springer, 1978.

叶公节, 刘兆汉.电离层波理论[M].北京:科学出版社, 1983.

XU Bin, WU Jian, WU Zhensen, et al.The temperature enhancement induced by ionosphere heating in low region[J].Progress in natural science, 2008, 18(11):1339-1343.

黄文耿, 古士芬.大功率无线电波与低电离层的相互作用[J].空间科学学报, 2003, 23(3):181-187. HUANG Wengeng, GU Shifen.Interaction between the powerful high-frequency radio wave and the lower terrestrial ionosphere[J].Chinese Journal of Space Science, 2003, 23(3):181-187. (in Chinese)

BANKS P.Collision frequency and energy transfer-electrons[J].Planetary and Space Science, 1966, 14(11):1085-1103.

BANKS P.Collision frequencies and energy transfer-ions[J].Planetary and Space Science, 1966, 14(11):1105-1122.

STUBBE P, VARNUM W S.Electron energy transfer rates in the ionosphere[J].Planetary and Space Science, 1972, 20(8):1121-1126.

STUBBE P.A new collisional relaxation model for small deviations from equilibrium[J].Journal of Plasma Physics, 1987, 38(1):95-116.

BERNHARDT P A, DUNCAN L M.The feedbackdiffraction theory of ionospheric heating[J].Journal of Atmospheric and Solar-Terrestrial Physics, 1982, 44(12):1061-1074.

倪彬彬, 赵正予, 项薇, 等.高频泵波加热电离层的数值模拟[J].电波科学学报, 2004, 19(3):274-279. NI Binbin, ZHAO Zhengyu, XIANG Wei, et al, Numerical modeling of ionospheric modification with powerful HF pump waves[J].Journal of Radio Science, 2004, 19(3):274-279. (in Chinese)

黄文耿, 古士芬.大功率无线电波与高电离层的相互作用[J].空间科学学报, 2003, 23(5):343-350. HUANG Wengeng, GU Shifen.The heating of upper ionosphere by powerful high-frequency radio waves[J].Chinese Journal of Space Science, 2003, 23(5):343-350. (in Chinese)

黄文耿, 古士芬, 龚建村.大功率高频无线电波加热电离层[J].电波科学学报, 2004, 19(3):296-301. HUANG Wengeng, GU Shifen, GONG Jiancun.Ionospheric heating by powerful high-frequency radio waves[J].Journal of Radio Science, 2004, 19(3):296-301. (in Chinese)

KERO A, BOSINGER T, POLLAR P, et al.First EISCAT measurement of electron-gas temperature in the artificially heated D-region ionosphere[J]. Annales Geophysicae, 2000, 18(9):1210-1215.

LOFAS H, IVCHENKO N, GUSTAVSSON B, et al.F-region electron heating by X-mode radio-waves in under-dense conditions[J].Annales Geophysicae, 2009, 27(6):2585-2592.

徐彬, 王占阁, 薛昆, 等.极区二维人工电离层加热数值仿真[J].电波科学学报, 2010, 25(1):1-6. XU Bin, WANG Zhange, XUE Kun, et al.2D numerical simulation of artificial ionospheric heating in polar region[J].Journal of Radio Science, 2010, 25(1):1-6. (in Chinese)

徐彬, 王占阁, 吴军, 等.2009年夏季极区电离层加热实验研究[J].极地研究, 2010, 22(4):334-347. XU Bin, WANG Zhange, WU Jun, et al.Observation of the polar ionospheric heating experiment in summer, 2009[J].Chinese Journal of Polar Research, 2010, 22(4):334-347. (in Chinese)

HEDIN A E.Extension of the MSIS thermospheric model into the middle and lower atmosphere[J]. Journal of Geophysical Research, 1991, 96(A2):1159-1172.

BILITZA D.International reference ionosphere-status 1995/96[J].Advances in Space Research, 1997, 20(9):1751-1754.

BLAGOVESHCHENSKAYA N F, CARLSON H C, KORNIENKO V A, et al.Phenomena induced by powerful HF pumping towards magnetic zenith with a frequency near the F-region critical frequency and the third electron gyro harmonic frequency[J].Annales Geophysicae, 2009, 27(1):131-145.
