频率可重构超宽带天线研究

田雨波; 谭冠南

频率可重构超宽带天线研究

江苏科技大学电子信息学院, 江苏镇江 212003

详细信息

作者简介:
田雨波(1971-),男,满族,辽宁人,江苏科技大学教授,博士,2009年到美国UCLA做访问学者。目前主要研究方向为计算智能应用于电子学与电磁学问题;谭冠南(1988-),男,江苏人,江苏科技大学电子信息学院硕士生,主要研究方向为可重构天线。

通信作者:
谭冠南 E-mail:tanguannan@163.com

中图分类号: TN822.8
计量
- 文章访问数: 116
- HTML全文浏览量: 22
- PDF下载量: 45
出版历程
- 收稿日期: 2011-05-15
- 网络出版日期: 2020-12-30
- 发布日期: 2012-04-29

Frequency reconfigurable UWB antenna

School of Electronics and Information, Jiangsu University of Science and Technology, Zhenjiang Jiangsu 212003, China

摘要

摘要: 超宽带天线和可重构天线是当今天线领域研究的热点。将可重构天线技术应用到超宽带天线设计中,讨论了频率可重构超宽带天线的设计思路。以印刷单极子椭圆天线为原型,给出了两个可重构天线的具体结构,并对天线进行了可重构带阻设计,避免与相关频段之间的干扰。仿真结果表明:重构后天线Ⅱ的低频获得了扩展,其相对尺寸的长和宽分别减小到最大工作波长的0.116倍和0.087倍,工作频段为0.174~10.9GHz,可重构阻带为5.1~5.95GHz,带宽比可高达62:1.
- 超宽带天线 /
- 可重构天线 /
- 可重构带阻
Abstract: Nowadays, UWB antennas and reconfigurable antennas are both hot research fields.In this paper, the technology of reconfigurable antenna is applied to ultra-wideband antennas, and the basic design idea of frequency reconfigurable UWB antenna is discussed.Based on the elliptical planar monopole antenna, two reconfigurable UWB antennas are presented.In order to avoid interference with other communication band, an antenna is designed with a reconfigurable bandnotch. The simulation results of antenna Ⅱ show that after reconfiguration, the LF band is extended.Simultaneously, the length and width of relative size are reduced to 0.116 and 0.087 times of the maximum operating wavelength.The antenna Ⅱ operates at 0.174~10.9 GHz, and the reconfigurable notched band is 5.1~5.95 GHz.Moreover, the bandwidth ratio is 62:1.
- UWB antenna /
- reconfigurable antenna /
- reconfigurable notched-band

HTML全文

参考文献(14)

钟顺时, 梁仙灵, 延晓荣.超宽带平面天线技术[J]. 电波科学学报, 2007, 22(2):308-315. ZHONG Shunshi, LIANG Xianling, YAN Xiaorong. UWB planar antenna technology[J].Chinese Journal of Radio Science, 2007, 22(2):308-315. (in Chinese)

BAI Xiaofeng, ZHONG ShunShi, LIANG Xianling. Leaf-shaped monopole antenna with extremely wide bandwidth[J].Microwave and Optical Technology Letters, 2006, 48(7):1247-1250.

XIA Y Q, DUAN Z G.Compact CPW-fed dual ellipses antenna for ultra-wideband system[J].Electronics Letters, 2008, 44(9):567.

LIANG X L, ZHONG S S, WANG W.Elliptical planar monopole antenna with extremely wide bandwidth[J].Electronics Letters, 2006, 42(8):441-442.

HOOD A Z, KARACOLAK T, TOPSAKAL E.A small antipodal vivaldi antenna for ultrawide-band applications[J].IEEE Antennas and Wireless Propagation Letters, 2008, 7:656-660.

SCHAUBERT D, FARRAR F, HAYES S, et al. Frequency-agile, polarization diverse microstrip antennas and frequency scanned arrays:US, 4367474[P].1983-01-04.

SMITH J K.Reconfigurable program (RECAP). DARPA (美国国防高级研究计划署), 1999.

王安国, 张佳杰, 王鹏, 等.可重构天线的研究现状与发展趋势[J].电波科学学报, 2008, 23(5):997-1002+1008. WANG Anguo, ZHANG Jiajie, WANG Peng, et al.Recent research and developing trends of reconfigurable antennas[J].Chinese Journal of Radio Science, 2008, 23(5):997-1002+1008.

T.Al-Maznaee, H.E.Abd-El-Raouf.Design of reconfigurable patch antenna with a switchable V-slot[J]. Progress In Electromagnetics Research C, 2009, 6:145-158.

吕文俊, 朱洪波.陷波特性平面超宽带天线的研究进展[J].电波科学学报, 2009, 24(4):780-785. LV Wenjun, ZHU Hongbo.On the frequency notched planar ultra-wideband antennas[J].Chinese Journal of Radio Science, 2009, 24(4):780-785.

Arezou Edalati, Tayeb A.Denidni.A compact UWB antenna with dual band-notched characteristics[J]. Microwave and Optical Technology Letters, 2010, 52(5):1183-1186.

A.M.Abbosh, M.E.Bialkowski.Design of UWB planar band-notched antenna using parasitic elements[J].IEEE Transactions on Antenna and Propagation, 2009, 57(3):796-799.

Y.Song, Y.C.Jiao, T.L.Zhang, et al..Frequency notched UWB slot antenna with a fractal-shaped slot[J].J.of Electromagn.Wave and Appl., 2009, 23:321-327.

Li-Na Zhang, Shun-Shi Zhong, Chen-Zhu Du, et al.. Compact UWB planar monopole antenna with bandnotch function[J].Microwave and Optical Technology Letters, 2009, 51(8):1908-1911.
