键盘按键信息的近场截获研究

杜玉雷; 吕英华; 张金玲; 张南

doi:10.13443/j.cjors.2013070701

键盘按键信息的近场截获研究

北京邮电大学电子工程学院,北京 100876

详细信息

通信作者:
杜玉雷 E-mail: dylbupt@gmail.com

计量
- 文章访问数: 115
- HTML全文浏览量: 30
- PDF下载量: 9
出版历程
- 收稿日期: 2013-07-06
- 网络出版日期: 2020-12-30
- 发布日期: 2014-08-29

Recovery of keystrokes from electromagnetic radiation in near-field

School of Electronic Engineering, Beijing University of Posts and Telecommunications,Beijing 100876, China

摘要

摘要: 计算机键盘在正常工作时会伴随产生电磁骚扰噪声，未授权人员若窃取这些电磁噪声经分析处理便可还原键盘的按键信息.经测试发现键盘的电磁辐射主要来自键盘内的印制电路板（Printed Circuit Board，PCB）及接口电缆互连结构，在连接处产生共模电压源并激励PCB板和接口电缆构成的共模回路向外发射电磁波.通过建立理论模型，分析了键盘产生伴随电磁辐射的机理，并基于该模型对PCB板-电缆互连结构进行了定量计算及电磁全波仿真.用实验的方法在近场截获了键盘的按键信息.实验结果表明：计算机键盘伴随产生的电磁骚扰噪声中含有按键信息并可在近场被截获.
- 电磁信息安全 /
- TEMPEST /
- 失衡差分模型 /
- 近场截获
Abstract: Computer keyboards radiate electromagnetic（EM)disturbance noises unintentionally during working.Unauthorized person can recover keystrokes through receiving and analyzing these EM noises.From the experimental testing，we have found that the EM radiation of the keyboard mainly comes from the printed circuit board(PCB)and the transmitting cable.A common-mode voltage source is produced at the interface between the PCB and transmitting cable due to the unbalanced structure.And，this source can drive the PCB and the transmitting cable to radiate EM waves.Firstly，the principle of radiating EM waves from keyboard unintentionally is analyzed by using imbalance difference model.Then，based on this model the radiation from the PCB-cable interconnecting structure is calculated in theory and simulated through 3D full-wave EM simulation software.Finally，the keystrokes are recovered in the near-field through the experiment.The results demonstrate that the information of keystrokes are contained in the EM disturbance noises and can be eavesdropped in the near-field.

HTML全文

参考文献(17)

IEC.CISPR 22-2006，Information Technology Equipment-Radio Disturbance Characteristics-Limits and Methods of Measurement［S］.Geneva:CISPR subcommittee I，2006．

VANECK W.Electromagnetic radiation from display units:an eavesdropping risk？［J］.Computers and Security，1985，4(4):269-286．

KUHN M G.Security limits for compromising emanations［C］// Proceedings of the 7th International Workshop Cryptographic Hardware and Embedded Systems.Berlin:SpringerVerlag，2005:265-279．

KUHN M G.Compromising emanations:Eavesdropping Risks of Computer Displays［D］.Cambridge:University of Cambridge Computer Laboratory，2003．

DU Yulei，LÜ Yinghua，ZHANG Jinling，et al.Estimation of eavesdropping distance from conducted emission on network cable of a PC［C］// The 6th Asia-Pacific Conference on Environmental Electromagnetics（CEEM).Shanghai，Novomber 6-9，2012:347-350．

SEKIGUCHI H，SETO S.Measurement of computer RGB signals in conducted emission on power leads［J］.Progress in Electromagnetics Research C，2009，7:51-64．

杜玉雷，吕英华，莫凡，等.屏幕泄漏信息最佳截获频段的一种选取方法［J］.北京邮电大学学报，2013，36(1):54-58．DU Yulei，LÜ Yinghua，MO Fan，et al.A method for choosing the best frequency range for receiving the compromising emanations form in PC display［J］.Journal of Beijing University of Posts and Telecommunications，2013，36(1):54-58.（in Chinese)

张洪欣，吕英华，韩宇南，等.计算机电磁辐射信息识别特性研究［J］.电波科学学报，2004，19(5):553-559．ZHANG Hongxin，LU Yinghua，HAN Yunan，et al.Study on information recognizability of electromagnetic radiation arising from computer［J］.Chinese Journal of Radio Science，2004，19(5):553-559.（in Chinese)

张浩斌，吴昌英，董士伟，等.显示器电磁泄漏信息的接收和重现［J］.电波科学学报，2002，17(4):422-425．ZHANG Haobin，WU Changying，DONG Shiwei，et al.Information reception and recovery of EM leakness from displayer［J］.Chinese Journal of Radio Science，2002，17(4):422-425.（in Chinese)

张静勤.键盘电磁泄漏发射信息还原关键技术研究［D］.北京:北京交通大学，2010．ZHANG Jingqin.Information Recover Based on Compromising Electromagnetic Emanations of Keyboard［D］.Beijing:Beijing Jiaotong University，2010.（in Chinese)

VUAGNOUX M，PASINI S.Compromising electromagnetic emanations of wired and wireless keyboards［C］// The 18th USENIX Security Symposium.Montreal，Aug 10-14，2009:1-16．

VUAGNOUX M，PASINI S.An improved technique to discover compromising electromagnetic emanations［C］// The 2010 IEEE International Symposium on Electromagnetic Compatibility.Florida，July 25-30，2010:121-126．

PAUL C R.A comparison of the contribution of common-mode and differential-mode currents in radiated emissions［J］.IEEE Transactions on Electromagnetic Compatibility，1989，31(2):189-193．

SMULDERS P.The threat of information theft by reception of electromagnetic radiation from RS-232 cables［J］.Computers and Security，1990，9:53-58．

TOYOTA Y，MATSUSHIMA T，IOKIBE K，et al.Experimental validation of imbalance difference model to estimate common-mode excitation in PCBs［C］// IEEE International Symposium on Electromagnetic Compatibility.Detroit，August 18-22，2008:1-6．

UCHIDA H.Fundamentals of Coupled Lines and Multiwire Antennas［M］.Tohoku:Sasaki Printing and Publishing Company，1967．

WATANABE T，WADA O，MIYASHITA T，et al.Common-mode current generation caused by difference of unbalance of transmission lines on a printed circuit board with narrow ground pattern［J］.IEICE Transactions on Communications，2000，E83-B(3):593-599．
