基于局域预测的动载天线伺服控制策略研究

曹海青; 王渝; 杜明芳; 方建军

doi:10.13443/j.cjors.2013041001

基于局域预测的动载天线伺服控制策略研究

1.
北京理工大学自动化学院,北京100081
2.北京联合大学自动化学院,北京100101

详细信息

通信作者:
曹海青 E-mail:cxy8888@bit.edu.cn

计量
- 文章访问数: 55
- HTML全文浏览量: 20
- PDF下载量: 9
出版历程
- 收稿日期: 2013-04-09
- 网络出版日期: 2020-12-30
- 发布日期: 2014-02-27

Control policy of the moving antenna servo system based on local prediction

1.
School of Automation, Beijing Institute of Technology,Beijing 100081, China
2.College of Automation, Beijing Union University, Beijing 100101, China

摘要

摘要: 针对中小涌浪的扰动，研究了一种基于少量数据的局域预测方法，应用于海面小型漂浮式动载天线跟踪卫星的方位和俯仰伺服控制中.以天线系统的少量位置数据为基础，采用局域预测算法预测天线的位置，计算天线指向将偏离卫星的偏差值，进行天线指向偏离卫星的补偿控制；基于天线位置间相关性，研究了局域预测算法并进行仿真验证；根据天线系统的组成设计了天线方位伺服控制器，并通过matlab仿真和半实物仿真验证了局域预测伺服控制策略的可行性、可靠性和鲁棒性.
- 伺服控制 /
- 动载天线 /
- 局域预测 /
- 跟踪
Abstract: A local predictive method based on few data is applied in the azimuth and elevation servo control of the small moving antenna floating on sea under disturbances from medium and small surges in the process of automatic tracking satellite.The positions of the antenna are predicted by the local predictive method on the basis of the few data of the antenna positions，the calculation error between the antenna direction and the satellite will be input to the controller to control the antenna to track satellite.The local predictive algorithm is designed and verified by simulation based on the correlation among the antenna positions.The azimuth controller is designed on the basis of the antenna servo system construction and verified by matlab and hardware-in-loop simulation.Experimental results validate its feasibility，reliability and robustness.
- servo control /
- moving antenna /
- local prediction /
- track

HTML全文

参考文献(5)

赵来定，曹伟.动载体天线稳定系统［J］.现代电子技术，2006，220(5):33-36．ZHAO Laiding，CAO Wei.Antenna stabilization system on moving vehicles［J］.Modern Electronics Technique，2006，220(5):33-36.

李积德.船舶耐波性［M］.哈尔滨：哈尔滨工程大学出版社，2007：1-29．

刘煜，张科，李言俊.一种位置随动控制系统的建模与仿真研究［J］.弹箭与制导学报，2005，25(2):4-6．LIU Yu，ZHANG Ke，LI Yanjun.Modeling and Simulation research of control system of a random position［J］.Journal of Projectiles，Rockets，Missiles and Guidance，2005，25(2):4-6.

胡寿松.自动控制原理［M］.4版.北京：科学出版社，2001：558-566．

翁怡婵，杨金湘.台湾海峡漂移物运动轨迹的数值模拟［J］.厦门大学学报:自然科学版，2009，48(3):446-449.WENG Yichan，YANG Jinxiang.Simulation of floater trajectory in Taiwan Strait［J］.Journal of Xiamen University: Natural Science，2009，48(3):446-449.
